Stainless Steel / RGB LED
ECS-RGB-01

COLOR CHANGING LED LIGHTING SYSTEM

Eyeleds® ColorEYE RGB is a decorative, color changing LED lighting system. The product is available as single, linkable LED unit which makes ColorEYE RGB suited for a vast variety of indoor applications.

ColorEYE RGB must be operated by a special driver. Two types of drivers are possible:

  1. Eyeleds® ColorEYE RGB Sequencer box and an existing wall mounted on/off switch. The color cycle mode, runs automatically and continuously when the system is switched on. Each color within the spectrum can be selected as a static color, simply by swiftly switching on the system off and on.
    or
  2. Eyeleds® ColorEYE RGB Controller box is a Bluetooth driver. With the BLE-ND app from the App store a Bluetooth Low Energy connection can be made and the desired color can be selected with the app. All RGB colors and dimming is possible.





APPLICATIONS:

Natural stone
Hardwood & laminate
Carpet (tiles)
(Entrance) Matting
Quartz carpet
Stair treads, stringers & risers
Baseboards & profiles
Countertops & cabinets



PRODUCT CONFIGURATION & DIMENSIONS

Eyeleds® ColorEYE RGB is a single, linkable LED unit with two 80 cm cables and pre-attached male and female IP67 plug connectors.









FEATURES & BENEFITS

Decorative RGB

State of the art, decorative RGB LED lighting system

Endless creativity

Revolutionary low profile design allows for endless creativity in a myriad of applications

Surface thickness of only 7 mm

Flush mounted LED units that require a flooring or surface thickness of only 7 mm

High quality components

High quality components: UV-resistant, polycarbonate lens and a stainless steel housing

Water-resistant

Water-resistant lighting system that is safe around damp and wet locations (IP67)

Long lasting

Long lasting, energy efficient LED technology with a power consumption of 0.45W per unit

SPECIFICATIONS



Power consumption: 0.45W, 37mA


Voltage: 12V DC


Rated life: Up to 50.000 Hours


Materials: Lens: PC | Fixture: Stainless Steel 316


Walkover pressure: Max 285 kg


Surface temperature: Max 34°C


Environment: IP67 / Indoor Use Only


Warranty: 5 Years Limited


Standards: CE

DOWNLOADS/INSTRUCTIONS







ACCESSORIES

Built-In Driver EIA-10000
12W / 12V DC
220-240V
max. 40 pcs of ColorEYE

Built-In Driver EIA-15000
20W / 12V DC
220-240V
max. 40 pcs of ColorEYE
L 51/B 51/H 24 mm

Plug-In Driver EIA-11000
5W / 12V DC
220-240V
max. 15 pcs of ColorEYE


RGB Sequencer Box
CSA-30000
suitable for ColorEYE RGB and ColorEYE RGB BLE

T-Splitter EIA-20000

Extension Cable
EIA-30002 – 100 cm (1.6”)
EIA-30003 – 300cm (3.2”)
EIA-30004 – 600cm (9.8”)


Clamp Ring (carpet) EIA- 60000

End Stop EIA-40000
